Support 4G Module Industrial PC Intel I3 8th DDR4 32GB Windows/Linux
| Place of Origin | Shenzhen，China |
|---|---|
| Brand Name | HJS/OEM |
| Certification | CE/ROHS |
| Model Number | HJS-IPC-HCG |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| CPU | Intel I3 8th | Ram | 32 GB |
|---|---|---|---|
| Storage | M.2 2280 SSD | Interface | HDMI, VGA, DP |
| USB | USB 2.0x4, USB 3.0x4 | WIFI | Support 4G Module |
| Size | 252 X 205 X 72mm | Multi Displays | Three Display |
| Highlight | 4G Module Industrial PC,Industrial PC I3 8th |
||
Product Description
ODM/OEM
We understand you might have different ideas, as one stop solution manufacturer starts from bared board to assemble line, we have all facility to make your ideas become real.
Our further service includes but not limited below:
☑ Logo
☑ Profile Colors
☑ Security
☑ Interfaces Customization
☑ Virtualisation
☑ And so on...
Text us or email us, let us start our “Dream becomes true” Journey.
Hairy Crab G Series Windows/Linux Embedded Industrial PC Intel I3 8th DDR4 32GB
Products Description
Features
* Intel IPC-HCG
* Supports Intel I3 8th processor
* 2 x channel DDR4 Memory
* 1 x M.2 2280
* 4 x USB2.0, 4 x USB3.0
* Displays:1 x HDMI, 1 x VGA, 1 x DP
Applications: Digital Signage, Airport, White-board for Education, Conference Room, etc.
Specification
| Processor System | Laptop Intel Elkhart Lake/Kaby Lake/Tiger Lake CPU |
| Memory | 2xSO-DIMMDDR4 |
| 32GB | |
| Power Supply | Phoenix end 2PIN(JF1)seat |
| Support wide voltage 9~36v | |
| Display Interface | 1xHDMI Type-A 3840x2160@24Hz(TGL 4K60Hz) |
| 1xDP Type-A 3840x2160@60Hz | |
| 1xVGA 1920x1080@60Hz | |
| EDP LVDS 2x15 2.0mm | |
| Storage | 1xM.2 2280 SSD |
| Expansion Plate End | 1xJSATA;1xMINI PCIE port |
| 1xMSIM card holder | |
| 6xD89 COM port | |
| 4xUSB2.0 Type-A | |
| 1xGPIO 16x16 interface,1xfour-hole terminal:power switch and hard disk lamp | |
| USB | 4xUSB3.0, 4xUSB2.0 |
| Net Interface | Realtek 8111H Gigabit Ethernet |
| 2xRJ45 port 10/100/1000Mbps | |
| Audio Frequency | ALC897 HD sound card chip |
| (Mic-In Line-Out two in one 3.5mm) interface | |
| COM port | 6xD89 COM, COM1&COM2(RS485/RS232) |
| GPIO | 32bit 16 in and 16 out |
| One-click restore | J_GHOST1 |
| One-key restart | J_SYSRST |
| self-starting | J AT1 |
| Size | 252x205x72 mm |
